G.LAMEN – HIGH-RATE CLARIFIER MODULE

G.LAMEN – HIGH-RATE CLARIFIER MODULE

The G.LAMEN system is an upgraded version of the conventional sedimentation process.
It integrates multiple treatment stages into a single compact module, designed to improve separation efficiency and reduce equipment footprint.

The module performs two primary functions:

  • Oil and grease separation, including removal of floating scum layers.

  • Separation of suspended solids, covering both easily settleable and difficult-to-settle particles.

Technical Features and Advantages

  • Optimized bottom geometry: The reduced residual sludge volume minimizes tank weight and material consumption.

  • Integrated process design: Combines oil separation and sedimentation in a single module, reducing installation area and capital cost.

  • Modular configuration: Facilitates easy integration into existing treatment systems and simplifies maintenance.

  • Stable hydraulic performance: Ensures uniform flow distribution and consistent settling efficiency under variable operating conditions.

Application Areas

The G.LAMEN High-Rate Clarification Module is suitable for the following applications:

  • Potable water treatment plants.

  • Electroplating and metal finishing wastewater treatment.

  • Textile and dyeing industrial wastewater systems.

  • Industrial park and municipal wastewater treatment facilities.

Design Considerations

When implementing the G.LAMEN module, the following design parameters should be evaluated:

  • Influent characteristics (oil concentration, SS, TDS, temperature, and pH).

  • Target effluent quality and discharge standards.

  • Available footprint and hydraulic head.

  • Integration with upstream and downstream treatment units.

Device selection

Tank size
Fluids

Q&A

-> An industrial exhaust fan is designed to remove air, heat, and fumes from a workspace, while a centrifugal fan uses centrifugal force to move air efficiently through ducts or systems. Centrifugal fans are commonly used in dust collection and ventilation systems requiring high pressur

-> A cyclone dust collector primarily separates larger dust particles using centrifugal force. It is not effective for fine particles like PM2.5. To remove PM2.5 efficiently, a bag filter or electrostatic precipitator should be used after the cyclone stage

-> A gas scrubber is typically used to treat acidic or chemical exhaust gases such as SO₂, HCl, NH₃, and VOCs. Depending on the scrubbing solution and design, it can also capture particulates and neutralize harmful emissions from industrial processes

-> An industrial mixer is suitable for surface or tank-level mixing in chemical or wastewater treatment systems, while a submersible mixer is ideal for continuous agitation in deep tanks or equalization basins to prevent sedimentation

-> A high-quality submersible mixer typically lasts between 5 to 10 years, depending on material quality, operating conditions, and maintenance frequency. Using stainless steel materials and regular servicing can extend the mixer’s lifetime

-> A belt filter press can process between 5 to 50 cubic meters of sludge per day, depending on sludge concentration, belt width, and machine capacity. Proper conditioning and polymer dosing improve dehydration efficiency

-> Yes, a DAF system is highly effective in separating oil, grease, and suspended solids from food-processing wastewater. By injecting microbubbles, it floats contaminants to the surface for removal, improving overall treatment efficiency
No. Model Capacity Rectangle Tank (m)
m3/h Length Width Height
1 LAME-G01 0 - 5 1.5 1.0 2.5
2 LAME-G02 0 - 10 3.0 1.5 2.5
3 LAME-G03 10 - 15 3.5 1.5 3.0
4 LAME-G04 15 - 20 4.0 1.7 3.0
5 LAME-G05 20 - 30 4.5 2.3 3.0
6 LAME-G06 30 - 40 5.0 2.5 3.0
7 LAME-G07 40 - 50 5.5 3.0 3.0
8 LAME-G08 50 - 60 6.5 3.0 3.0
9 LAME-G09 60 - 70 5.0 4.5 3.5
10 LAME-G10 70 - 80 5.5 5.0 3.5
11 LAME-G11 80 - 100 6.0 5.5 3.5
12 LAME-G12 100 - 120 6.5 6.0 3.5
13 LAME-G13 120 - 140 7.0 6.5 3.5
14 LAME-G14 140 - 160 7.5 7.0 3.5
Note: Each product is designed and manufactured to suit each specific application.
